LEMS IS500 Coilover Kit
LEMS IS500 Coilover Kit
Regular price
$5,719.00 AUD
Regular price
Sale price
$5,719.00 AUD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Product details
[LEMS IS500 Coilover Kit]
Based on the "F" data, this kit is specifically tailored for the IS500, providing a comfortable ride at low speeds and a stable, secure ride at high speeds.
Based on the RCF coilovers (developed at Fuji Speedway) tuned with LEMS' original damping force settings, this kit is tailored to the IS500's unique character!
Designed for driving on public roads, expressways, mountain passes, and even on circuits, it responds precisely to the driver's wishes, ensuring excellent control, straightforward handling, and a comfortable ride.
With 20 levels of damping adjustment, you can customize the feel to your liking while also achieving a firm grip when cornering.
Each product is carefully assembled by skilled craftsmen in Japan.
*The coilover case color is brown. The color may appear different depending on the display.
[Basic Spring Rate]
Front: 14kg (standard),
Rear: 16kg (standard).
*The above values are the standard spring rates, but we can accommodate changes of up to +/-2kg when ordering. Please note this in the comments section.
However, the values in the installation instructions are for the standard model only.
Recommended settings: Lowering front and rear 25-30mm, lowering damping front and rear 10 clicks (maximum 20 clicks).
*The demo car lowered the front 46mm and the rear 35mm.
*Dampening Adjustment Notes :
Do not lower the damping setting more than 20 clicks.
Set both sides to the same position.
[Standard Reference Data]
Front: 650mm from bottom of factory wheel rim to fender arch
; Rear: 638mm from bottom of factory wheel rim to fender arch
. *NAVI and AI-AVS do not function.
(AVS: Adaptive Variable Suspension System)
*Product color and spring color are subject to change without notice.
Thank you for your understanding.
[Compatible models]
- IS500 (from September 2022)
Delivery time : 30 to 90 days
*Delivery may take up to 30 days. If you cannot wait, please inquire about the current delivery time before placing your order.
Please note that cancellations are not accepted after Order
